MSD 89611 Multi Purpose Relay

The SPST Waterproof High Current Relay is rated at 30 amps with an input voltage of 12 volts DC, supplied with Socket Harness.;<br><br>MSD's waterproof relay are ideal for use on electric fuel pumps, water pumps, cooling fans, off-road lights, and any other application that is exposed to muddy or wet conditions. This relay handles 40 amps momentary and 30 amps for continuous use. The pigtail harness has 7 in. long leads w/ heavy duty 12 &amp; 18 gauge wire. The connector has the wires molded in rubber and a gasket for a leak proof seal. Ideal for use on marine applications and vehicles that are power-washed out (Jeeps, 4x4 Trucks, UTV's, and dirt track race cars).;

• Waterproof relay w/ pigtail harness & sealed connector
• 40/30Amp â€" 30 AMP continuous load & 40 AMP momentary
• 12-Volts DC
• Works in normally open or normally closed circuits
• Pigtail wires are 7” long
• Wire Gauge: (3) 12 gauge wires on blue (30 common), yellow (87 normally open), red (87a normally closed) â€" (2) 18 gauge wires on black (85 ground) & white (86 +12V)
• Metal mounting bracket â€" can be mounted under-hood or just about any other location on vehicle
• Ideal for use in: marine, dirt track cars, and off-road trucks & Jeeps
